3.5KW AC DC8.3A12V Dynamo Brushless High Output Alternator
Selft-Exciting Single-Phase Dynamo
Model tyep: GFA174-3.5
Standy Power: 4.0KW
Rated Power: 3.5KW
Shaft Type: Taper Shaft 1:5/1:5.333
1. Cast aluminum shell
2. Easy to install with many kinds of machine,such as
gasoline/diesel engine
3. 100% copper wire,and cold-rolled silicon steel
Insulation Class:CL.F(△T≦130K)
Power Factor:CosΦ=1(Single-phase);CosΦ=0.8(Three-phase)
Rated Voltage:110,115,120,220,230,240,110/220,115/230,120/240,
DC Output:12V/8.3A(Optional)
Excitation Type:Brushless
Packing.
We have different original packages for selling in different
counties. Package.
we also can custom the packages as you want..
We have strict packaging to ensure that the goods are not damaged
and safely reach your hands.
Delivery.
Generally, it will take 15 to 20 working days after receiving your
advance payment. The specific delivery time depends on the items
and the quantity of your order.
We will recommend the most suitable shipping method for you.
Single-Phase with Eur socket.(socket as request)
|
Double Bearing type with Socket |
Taper shaft type |
Single/Three-Phase with Lead output
|
TECHNICAL DATE |
Type | Rated Power | Max Power | Overall&Mounting Dimensions(mm) |
A | B | C | E | ΦF | Taper |
GFA174-2.0 | 50Hz-3000r.p.m | 2.0 | 2.3 | 345 | 269 | 80 | 23/52.3 | 17/19.17 | 1:5/ 1:5.333 |
60Hz-3600r.p.m | 2.5 | 2.8 |
GFA174-2.5 | 50Hz-3000r.p.m | 2.5 | 2.8 | 355 | 279 | 90 |
60Hz-3600r.p.m | 3.0 | 3.5 |
GFA174-3.0 | 50Hz-3000r.p.m | 3.0 | 3.3 | 375 | 299 | 110 |
47/63.2
|
26/25.4
|
1:5/ 1:5.3333
|
60Hz-3600r.p.m | 3.5 | 4.0 |
GFA174-3.5 | 50Hz-3000r.p.m | 3.5 | 4.0 | 395 | 319 | 130 |
60Hz-3600r.p.m | 4.0 | 4.5 |
GFA174-4.0 | 50Hz-3000r.p.m | 4.0 | 4.5 | 405 | 329 | 140 |
60Hz-3600r.p.m | 5.0 | 5.5 |
GFA174-5.0 | 50Hz-3000r.p.m | 5.0 | 5.5 | 415 | 339 | 150 |
60Hz-3600r.p.m | 5.8 | 6.5 |
Note:The data for your information only ,and changes based on
practicality |
